Item / model |
NTI-THL-54W |
|
|
Working size |
mm |
300X300X600 |
|
Heating type |
/ |
Graphite rod |
|
Power control |
/ |
Thyristor controlled |
|
Max. capacity |
L |
54 |
|
Loading capacity |
g |
HT area capacity × product’s density(g/cm3)×1000 1L=1000cm3 |
|
Input voltage |
/ |
380V±10%，50Hz/60Hz 3 phase 5 wire |
|
Equipment structure |
/ |
One power to one or two or four furnace |
|
Type |
/ |
Horizontal |
|
power |
Kw |
50 |
|
Max. temperature |
℃ |
1600 |
|
Working tem. |
℃ |
1500 |
|
Tem.uniformity |
℃ |
±5 |
|
working environment |
/ |
Vacuum or Argon、N2 atmosphere environment (micro-positive pressure) |
